liTE Smart controller V7 2-button WiFi

The controller, WiFi is a special controller for controlling the light sources of the system communicating on the WiFi protocol. Thanks to this, you can control the lighting in your home at any time and thus become the master of light.

It is fully compatible with iOS, Android, Amazon Alexa, Apple Siri shortcuts, Google Assistant, TUYA, Lidl.

Technical parameters:

Note: with neutral wire connection

Protocol: WiFi

Frequency: 2400MHz~2483.5MHz

Maximum RF output power: Wifi: 20 dBm

Network standby power (Pnet): 0.4W

Input power: AC 120 - 240 50 Hz / 60 Hz

Maximum current: 2x 10A

Load range: 2x 2300W / 2x 250W for LED lighting

Thermal fuse, protection against overheating: Yes

Current fuse, protection against overvoltage and overload: Yes

Communication protocol: WiFi, support Tuya.

Wireless range: 30 m line of sight, 10 m in built-up space

Operating temperature: -10°C to +40°C.

Operating humidity: 20% - 80%.

Dimensions: 4 x 4 x 1.8 cm (without holder)

Degree of protection: IP20

Package contents: Smart controller, user manual
