Standard: | TCP/IP |
Sensor: | 1/2.8 "" Progressive Scan CMOS |
Matrix size: | 8.3 Mpx |
Resolution: | 3840 x 2160 - 8.3 Mpx, 4K UHD |
Lens: | 2.8 mm |
View angle: | 107 ° |
Range of IR illumination: | 30 m |
White light LED illuminator range: | 20 m |
Audio: | • Microphone built-in,. Speaker built-in,. Alarm siren 110 dB. Audio transmission via network. Bi-directional audio streaming support |
Image compression method: | H.265 / H.264 |
Main stream frame rate: | 15 fps @ 8.3 Mpx |
Network protocols: | TCP, DHCP |
ONVIF: | + |
Network interface: | • Ethernet : 100 Mbps. Wi-Fi IEEE 802.11 b/g/n - 2.4 GHz |
WEB Server: | - |
Mobile phones support: | Access by a cloud (P2P). Android: Free application . iOS (iPhone): Free application |
Default admin user / password: | admin / - The administrator password should be set at the first start |
Default IP address: | DHCP |
Web browser access ports: | - |
PC client access ports: | - |
Mobile client access ports: | - |
Port ONVIF: | - |
RTSP URL: | - |
Memory card slot: | Micro SD memory cards up to 256GB support (possible local recording) |
Main features: | • Wi-Fi module - IEEE 802.11 a/b/g/n/ac/ax,. MIMO technology - increases the throughput of wireless link (multiple antennas transmission). Motion Detection. People detection. Alarm notifications - Sending instant motion-activated alerts to mobile phone. Intelligent object recognition in the field of view (human / animal / vehicle). D-ZOOM - Digital Zoom : 16x . LED Floodlight. Full Color - colorful night mode. Built-in alarm siren. Light and sound alarm. Active deterrence function. IMOU Cloud. RESET button |
Power supply: | 12 V DC / 1.5 A (power adapter included) |
Power consumption: | < 9.2 w |
""Index of Protection"": | IP66 |
Weight: | 0.57 kg (with bracket) |
Dimensions: | 128 x 114 x 84 mm (with bracket) |
Supported languages: | - |
Manufacturer / Brand: | DAHUA / IMOU |
